UV Master Technology

Highly concentrated UV radiations.

Easy To Handle

Spacious UV exposure chamber in stainless steel.

Long Lifetime

Protective quartz disk on the UV sensor cell.

Ondulex Reflector

Reflect  the maximum UV output.

The Bio-Link is a UVA, UVC or UVB irradiation system, mainly dedicated to the binding of nucleic acid to membranes and the removal of contamination by PCR. Its innovative design gives it unique characteristics:

  • Microprocessor controlled. The programmable microprocessor permanently controls the UV light emission. Irradiation stops automatically when the received energy corresponds to the programmed energy.
  • Reproducibility. Thanks to its UV sensor, the irradiation cycles are perfectly reproducible, regardless of the fluctuation in the intensity of the UV source. Simply program your energy and Bio-Link delivers it!
  • Consistent measure. The UV light sensor is placed above a well of light at the top of the irradiation chamber. The UV measurement is then collected in all the UV tubes and not just in one, for better consistency!
  • Ease of use. The large number of presets in units of energy or time makes the Bio-Link a very simple to use yet powerful instrument.
  • Durability. The Bio-Link combines the latest technology with the highest quality components: UV exposure chamber made of stainless steel, quartz protection disc on the UV sensor cell, highly resistant touch membrane keypad, …

KEY FEATURES

  • Precise irradiation in energy (Joules/cm2) or time (seconds)
  • Preset program for 0.120 J/cm2 to optimize nucleic acid binding
  • Storage of the last UV setting
  • Protective quartz disc on the UV sensor cell
  • Spacious stainless steel UV exposure chamber
  • Safety locking door with UV blocking observation window
  • Interchangeable UV wavelengths

Table Of Products

Our large choice of filter and unfiltered lamps range from 6 to 3×40 w-watt. Our filtered lamps are ideal for the fluorescence detection. The BL-Black-Light lamps provides a large light spectrum with 365nm UV and visible light. The UV germicidal 254nm lamps help to prevents contamination in research laboratories.

Table Of Products

Our large choice of filter and unfiltered lamps range from 6 to 3×40 w-watt. Our filtered lamps are ideal for the fluorescence detection. The BL-Black-Light lamps provides a large light spectrum with 365nm UV and visible light. The UV germicidal 254nm lamps help to prevents contamination in research laboratories.

Specifications
UV Source 5 x 8-watt
Either in 254nm (UV-C), 312nm (UV-B), 365nm (UV-A)
Energy Diplay

Two measurement ranges:

  • from 0.025 to 9.999 Joules
  • from 0.025 to 99.99 Joules
Expsure Time Display

Two measurement ranges:

  • from 00.10 to 99.59 minutes/seconds
  • from 000.1 to 599.5 minutes/seconds
Manual Control Manual energy exposure adjustment
Manual exposure time adjustment
Presets Energy: 9 presets
Exposure time: 9 presets
